Discussion Starter · #1 ·
Similar engine to the current Jetta.
1.5-liter EA211 turbo engine - 158 horsepower and 184 pound-feet of torque

Volkswagen redesigned and enlarged the displacement of the turbo powertrain used in the Jetta. This revised powerplant features VW’s modified version of the Miller cycle, where the intake valves are closed early in the induction stroke. Helps with fuel economy reportedly, but we won't know for sure until EPA MPG fuel economy ratings are released.

Front-wheel drive Taos versions will have an eight-speed automatic transmission, same as the Jetta

All-wheel drive versions will have a seven-speed DSG transmission. Pretty amazing that the Taos is getting a DSG. Raises my hopes for a crazy Taos R or something with AWD and DSG.


·
Registered
Joined
·
48 Posts
Volkswagen shared a press release about the Taos' engine and transmission. I'm pleasantly surprised a SUV like this is going to have an available dual clutch transmission. Didn't expect to see that.


Herndon, VA — Volkswagen announced today that the Taos compact SUV, which slots into the lineup below the Tiguan, will feature a new version of the EA211 turbocharged four-cylinder engine that currently powers the Jetta sedan. Making 158 horsepower and 184 pound-feet of torque, the new engine increases in size from 1.4 to 1.5 liters and offers a number of high-tech features designed to produce outstanding fuel economy.

Despite the engine having a larger displacement and being more powerful than the EA211 fitted in the Jetta, the engine is more efficient in fuel usage. It features Volkswagen’s modified version of the Miller cycle, where the intake valves are closed early in the induction stroke to help with fuel economy. For a turbocharged engine, it has a very high compression ratio of up to 11.5 to one.

Key features that help the Taos achieve a combination of low-speed torque and excellent fuel economy include:
  • APS coated cylinder liners—whereby iron powder is plasma coated onto the cylinder block—that reduce friction between the cylinder liner and piston rings. This process has been localized in the North American Region.
  • A map-controlled cooling module that warms the engine more quickly than the existing EA211 for efficiency and can control water flow in different parts of the engine.
  • Variable Turbine Geometry (VTG). This is the first volume-production turbocharger with this technology in the North American Region. This turbo is more efficient, provides higher boost pressure, and avoids wastegate mass flow.
  • A high-pressure injection system with up to 350 bar—up from 200 bar—which produces better atomization of the fuel/air mixture, a shorter injection time, optimized mixture formation, and lower particulate emissions.
The upshot is excellent fuel consumption and driving characteristics. The engine is mated to an eight-speed automatic transmission in the front-wheel-drive model, with a Sport mode. AWD models get a seven-speed DSG® dual-clutch automatic transmission.

“While electric vehicles are stealing the headlines these days, we are continuing to make great strides with technology on our internal combustion engines,” said Johan de Nysschen, Chief Operating Officer, Volkswagen Group of America. “The new 1.5-liter engine in the Taos uses the latest advances in gasoline-engine design to bring outstanding fuel economy to the compact SUV segment. The Taos will provide a further proof point for the ability of the Volkswagen North American Region to deliver the right products for our market requirements.”

The Taos is expected to go on sale in the summer of 2021 in both front- and all-wheel-drive forms. The vehicle is positioned in the largest U.S. vehicle segment, the compact SUV market, where 4 million vehicles were sold in 2019—around 24 percent of the market. It will slot into the VW compact SUV lineup below both the Tiguan and the all-electric ID.4 SUV.

Based on the MQB modular transverse architecture, the Taos is 11 inches shorter than the Tiguan at 174.2 inches overall. It will provide an excellent value, with outstanding fuel economy, interior space, tech, and available driver assistance features.

The Taos demonstrates the engineering capability of the North American Region (NAR), which now has more than 20,000 employees and seven engineering facilities in the U.S. and Mexico. These include the Oxnard Engineering Campus, which was recently expanded from 65,000 to 150,000 feet and now houses the Design Center California. Since 2016, the NAR has been given increasing responsibility for the products that are sold in Mexico, Canada and the U.S., and is tailoring vehicles to market requirements, which are often quite different to needs in other parts of the world, such as Europe.


·
Registered
2016 Audi S5
Joined
·
42 Posts
Speaking for the Mexican market, it was revealed that the TAOS will get the 1.4L TFSI EA211 engine with a 6-speed Tiptronic tranny that is currently found in the Jetta in that market.

I am not sure why VW decided to outfit Mexican TAOS with the old 1.4L TFSI engine and not the new 1.5L TFSI. From a production stand point, it would be much cheaper if they used 1 engine model for the North American market. I am guessing that the 1.4L TFSI engines from Brasil cranks out so much of them that it makes financial sense (think higher profit) for VW Mexico. TAOS for the Central and South American market will be built and supplied by the VW plant in Argentina. Those will also get the 1.4L TFSI engine. Once again, lesser markets get short-changed by VW.


·
Registered
Joined
·
48 Posts
Speaking for the Mexican market, it was revealed that the TAOS will get the 1.4L TFSI EA211 engine with a 6-speed Tiptronic tranny that is currently found in the Jetta in that market.

I am not sure why VW decided to outfit Mexican TAOS with the old 1.4L TFSI engine and not the new 1.5L TFSI. From a production stand point, it would be much cheaper if they used 1 engine model for the North American market. I am guessing that the 1.4L TFSI engines from Brasil cranks out so much of them that it makes financial sense (think higher profit) for VW Mexico. TAOS for the Central and South American market will be built and supplied by the VW plant in Argentina. Those will also get the 1.4L TFSI engine. Once again, lesser markets get short-changed by VW.
It must be a cost thing otherwise it doesn't make sense that VW wouldn't want to put their new powertrain in as many models as possible.


·
Registered
2016 Audi S5
Joined
·
42 Posts
More engine news:

Nov. 12, 2020
Motorpasion Mexico
Reported by: Mau Jaurez

Volkswagen announces the start of production of a new engine in Mexico: The 1.5 TSI

Volkswagen takes a new step in our country, a step of great weight, because although we are not talking about a new car, we are talking about a new engine that will be produced in Mexico and that will be destined for some of the most important models of the brand in our entire region. It is the 1.5 TSI engine that so far we have only seen in Mexico aboard the new generation Audi A1.
This engine is an evolution of the recognized and efficient 1.4 TSI. This new 1.5L TSI motor will be designated as the EA211 and starts its production at the Volkswagen engine plant in Silao, Guanajuato from 2021 with a total investment of 233.5 million dollars. This Volkswagen engine plan has been in charge of manufacturing nearly 14 million engines over 40 years of operation.

“Volkswagen Mexico was established in Guanajuato a fertile land for the generation of economic development. This investment for a new engine is a sign of the confidence that the Group has in a state (Guanajuato) that cares about creating the conditions for new projects and greater benefits for families to arrive,” said Steffen Reiche, Chairman of the Executive Board of Volkswagen de Mexico.

This new 1.5-liter turbo block receives improvements on different fronts to be more efficient, stable and better manage its work, its power is 158 hp (118 kW) and 184 lb-ft of torque, figures practically the same as those we found in the previous 1.4 TSI engine. This block will propel the Volkswagen Taos in the United States and Canada, we will surely see it reach new models over time since said engine will be sent to the Chattanooga plants, United States; to Volkswagen's Puebla plant in Mexico and also to the San José Chiapa plant in Puebla and where Audi manufactures the Q5.
With this we can expect a change of engines in several models of the brand, although we will have to wait to know which of them will receive this engine and will also be marketed in Mexico, remember that for now the Taos for Mexico will continue to use the 1.4 TSI engine and not the 1.5 TSI.
Source: Volkswagen anuncia el inicio de producción de un nuevo motor en México: el 1.5 TSI
